Bare Type Aluminium Conductor Steel Reinforced Cable With Round Wire Material Shape

Bare Type Aluminium Conductor Steel Reinforced Cable With Round Wire Material Shape

    • Bare Type Aluminium Conductor Steel Reinforced Cable With Round Wire Material Shape
    • Bare Type Aluminium Conductor Steel Reinforced Cable With Round Wire Material Shape
    • Bare Type Aluminium Conductor Steel Reinforced Cable With Round Wire Material Shape
  • Bare Type Aluminium Conductor Steel Reinforced Cable With Round Wire Material Shape

    รายละเอียดสินค้า:

    Place of Origin: ANHUI,CHINA
    ชื่อแบรนด์: Litong Global
    ได้รับการรับรอง: ISO9001&CCC
    Model Number: LT-201608311

    การชำระเงิน:

    Minimum Order Quantity: Negotiable
    ราคา: Negotiable
    ติดต่อ
    รายละเอียดสินค้า
    Model NO: ASTM B232 Type: Bare
    Conductor Type: Stranded Application: Overhead
    Conductor Material: ACSR Sheath Material: Bare
    Insulation Material: Bare Material Shape: Round Wire
    ได้รับการรับรอง: ISO,CCC Standard: ASTM B232 BS215
    Voltage: High Voltage Product Name: ACSR Conductor
    HS Code: 7614100000
    แสงสูง:

    acsr conductor

    ,

    overhead line conductor

    Product Description
    Aluminum Conductor Steel Reinforced Bare Aluminum Cable ACSR Conductor

    1.Application
    ACSR Conductor have been widely used in power transmission lines with various voltage levels, and also used in power lines across great Rivers, plain,highland etc. The cables have excellent advantages of high strength, large current carrying capacity and good catenary property as well as wear-resistance, anti-crush and corrosion-proof with simple structure, convenient and low cost installation and maintenance, large transmission capacity.

    2.Standard
    ASMTB232 Standard specification for concentric-lay-stranded aluminum conductors, coated-steel reinforced ACSR Conductor


    3.Specification
    Aluminum 1350-H19 wires, concentrically stranded around steel core wire for ACSR conductor is available with class A, B, or C galvanizing; "aluminized" aluminum coated(AZ); or aluminum - clad - (AW). Additional corrosion protection is available through the application of grease to the core or infusion of the complete cable.
    ASTM B232 Standard about ACSR Conductor
    Code Name Size No./Dia.of Stranding Wires Approx. Overall Dia. Approx. Weight
    AWG or MCM Aluminum Steel
    No./mm No./mm mm kg/km
    Turkey 6 6/1.68 1/1.68 5.04 54
    Swan 4 6/2.12 1/2.12 6.36 85
    Swanate 4 7/1.96 1/2.61 6.53 100
    Sparrow 2 6/2.67 1/2.67 8.01 136
    Sparate 2 7/2.47 1/3.30 8.24 159
    Robin 1 6/3.00 1/3.00 9 171
    Raven 1/0 6/3.37 1/3.37 10.11 216
    Quail 2/0 6/3.78 1/3.78 11.34 273
    Pigeon 3/0 6/4.25 1/4.25 12.75 343
    Penguin 4/0 6/4.77 1/4.77 14.31 433
    Waxwing 266.8 18/3.09 1/3.09 15.45 431
    Partridge 266.8 26/2.57 7/2.00 16.28 546
    Ostrich 300 26/2.73 7/2.12 17.28 614
    Merlin 336.4 18/3.47 1/3.47 17.5 544
    Linnet 336.4 26/2.89 7/2.25 18.31 689
    Oriole 336.4 30/2.69 7/2.69 18.83 784
    Chickadee 397.5 18/3.77 1/3.77 18.85 642
    Brant 397.5 24/3.27 7/2.18 19.61 762
    Ibis 397.5 26/3.14 7/2.44 19.88 814
    Lark 397.5 30/2.92 7/2.92 20.44 927
    Pelican 477 18/4.14 1/4.14 20.7 771
    Flicker 477 24/3.58 7/2.39 21.49 915
    Hawk 477 26/3.44 7/2.67 21.79 978
    Hen 477 30/3.20 7/3.20 22.4 1112
    Osprey 556.5 18/4.47 1/4.47 22.35 899
    Parakeet 556.5 24/3.87 7/2.58 23.22 1067
    Dove 556.5 26/3.72 7/2.89 23.55 1140
    Eagle 556.5 30/3.46 7/3.46 24.21 1298
    Peacock 605 24/4.03 7/2.69 24.2 1160





    4.Contact us

    Factory Add: Dangtu Industry Park,Ma'anshan,Anhui,China
    Tel: +86-555-6757570
    Fax: +86-555-6757655
    Mobile: +86-13855514957

    E-mail:nancylsl at hotmail.com
